ELECTRIC MOTORS
ELECTRONICS MARKET
#Electric motors
Threebond’s high-performance adhesives and sealants are designed to meet the demanding needs of electric motor assembly and maintenance. Our solutions are ideal for applications such as magnet bonding, case sealing, bearing fixing, core lamination, and coating, offering exceptional durability and reliability.
Whether bonding magnets securely to motor cores, sealing motor cases for protection against dust and moisture, or reinforcing bearings and laminations for enhanced performance, Threebond adhesives ensure superior adhesion, long-lasting stability, and resistance to harsh conditions.
| Product name | Type | Features | Applications | Appearance | Viscosity | Service temperature |
|---|---|---|---|---|---|---|
| 1133E | Acrylate Anaerobic liquid gasket | High elongation Excellent shock and vibration resistance Contact fluids resistance | Metal flange sealing Transmission case sealing Magnet bonding | Blue | 120 Pa.s | -40 to +150°C |
| 1160 | Acryl rubber Moisture curing sealant | Tin free Siloxane free Paintable sealant Heat and cold resistance ATF and oils resistance | Sealing of various parts | Black | 125 Pa.s | -40 to +120°C |
| 1207B | Acryl rubber Moisture curing sealant | Paintable sealant | Sealing of various parts | Black | 200 Pa.s | -30 to +150°C |
| 1226 | RTV Silicone (Alcohol) Moisture curing sealant | Good adhesion onto plastics | Electronic control unit sealing Light source control unit bonding Plastic case sealing | Gray | 97 Pa.s | -60 to +200(250)°C |
| 1227E | RTV Silicone (Alcohol) Moisture curing sealant | Excellent vibration and shock resistance High LLC resistance | Engine sealing Inverter sealing | Black | 310 Pa.s | -60 to +200(250)°C |
| 1357K | Acrylate resin Anaerobic adhesive | High strength Heat resistant Low halogen | Bonding of metallic part fitting areas Laminated core bonding Bearing fixing Vibrating motor Magnet bonding | Blue | 12 Pa.s | -40 to +175°C |
| 1359E | Acrylate resin Anaerobic adhesive | Solvent free acrylic base, anaerobic and heat curing | Magnet bonding | Green | 50 000 mPa･s | -40 to +150°C |
| 1360 | Acrylate resin Anaerobic threadlocker | High temperature resistance | Threadlocker Laminated core bonding | Red | 1 150 mPa.s | -40 to +200°C |
| 2088E | Two-Part Epoxy resin Room temperature curing | High heat resistance | Repair, bonding of metal, glass, ceramics, plastics Magnet bonding Securing of tip parts | Clear / Brown | (4 : 1) 40 : 4 Pa.s | -40 to +200°C |
| 2222P | Epoxy resin Heat curing | Solder resistant | Fixing and sealing electronic components Magnet bonding | Black | 45 Pa.s | -40 to +130°C |
| 2235L | Epoxy resin Heat curing | High heat resistance High Tg | Fixing and sealing electronic components Magnet bonding Reactor coil heat dissipation Securing of tip parts Bonding of needle and needle hub | Black | 80 Pa.s | -40 to +160°C |
| 2237J | Epoxy resin Heat curing | High heat resistance High Tg, low CTE | Fixing and sealing electronic components Magnet bonding Reactor coil heat dissipation | White | 115 Pa.s | -40 to +160°C |
| 2273D | Epoxy resin Heat curing | Compatible with fast induction curing process | Potting, fixing and sealing electronic components Magnet bonding | White | 75 Pa.s | -40 to +130°C |
| 2285D | Epoxy resin Heat curing | High heat resistance High Tg | Fixing and sealing electronic components Magnet bonding | White | 180 Pa.s | -40 to +180°C |
| 3042 | Acrylate UV and Heat curing resin | - | Coating, potting and fixing | Clear | 20 mPa.s | - |
| 3069J | Acrylate UV, Anaerobic and Primer curing resin | One-component solvent free acrylate | Magnet bonding | Blue | 110 Pa.s | -60 to +150°C |
| 3955 | Two-part Acrylic Room temperature curing adhesive | High strength elastic adhesive Fast curing Good heat resistance | Various car electrical components, sensors and motors bonding and fixing Magnet bonding | Clear blue Clear yellow | (1 : 1) 2.4 : 2.4 Pa.s. | - |
Some products are specialised and need to be used by a professional. Please, check the MSDS before use.
Related series
2000 & 2100 SERIES
TWO-COMPONENT EPOXY RESINS
2200 SERIES
ONE-COMPONENT EPOXY RESINS
3000 SERIES
UV CURING RESINS
APPLICATION EXAMPLE
Magnet bonding
Magnet bonding is a critical application in electric motor manufacturing, ensuring secure attachment and optimal performance. Threebond’s adhesives provide strong, durable bonds for magnets in demanding motor environments, offering superior resistance to vibrations, temperature changes, and wear. Our adhesives also play a key role in sealing motors, protecting components from moisture, dust, and other contaminants.
